Angled aluminum strut profile with cross-section 45x90x90L and a length of 6070 mm for building rigid machine frames, guard structures and assembly stations. Eight open slots (slot size 10) on a 45 mm modular grid provide unrestricted connectivity to the full Bosch Rexroth profile system. Supplied as a single rod in standard length; compatible cover caps available in signal gray and black.
Strut Profile 45x90x90L, Length 6070 mm, Anodized Aluminum, 8 Open Slots - Bosch Rexroth 3842537846
BOSCH REXROTH
Original product
Net price (excl. VAT)
€636.85
Item
BRR-3842537846
Manufacturer no.
3842537846
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842537846
Country of originGermany
Customs tariff number76042100
ConditionNew
Artikel
BRR-3842537846
The strut profile 3842537846 is an angled aluminum extrusion with cross-section 45x90x90L, part of the Bosch Rexroth 45 mm modular system. At 6070 mm in length it is well suited to load-bearing structures, machine enclosures, safety guards and workstation frames where rigidity and design flexibility are both required.
- 8 open slots (slot size 10) on all relevant faces - unrestricted connection points for fasteners, brackets and accessories from the Rexroth profile range
- Identical area moments of inertia in x- and y-direction (152.1 cm⁴ each) - equal bending stiffness about both principal axes
- Anodized aluminum, natural color - corrosion-resistant, easy to clean, suitable for hygiene-sensitive environments
- Profile surface area 21.2 cm², mass 5.7 kg/m - high load capacity at low dead weight
- Supplied as a single rod in standard length, packaging unit 1
Technical data
| Parameter | Value |
|---|---|
| Cross-section | 45x90x90L |
| Profile type | Angled |
| Length [L] | 6070 mm |
| Modular dimension | 45 mm |
| Profile slot | 10 |
| Open slots | 8 |
| Dimensions | 45x90x90 |
| Material | Aluminum, anodized |
| Color | Natural |
| Profile surface [A] | 21.2 cm² |
| Mass [m] | 5.7 kg/m |
| Weight (bar) | 35 kg |
| Area moment of inertia [lx] | 152.1 cm⁴ |
| Area moment of inertia [ly] | 152.1 cm⁴ |
| Moment of resistance [Wx] | 19.1 cm³ |
| Moment of resistance [Wy] | 19.1 cm³ |
| Torsional moment of inertia [It] | 34.9 cm⁴ |
| Moment of torsion resistance [Wt] | 11.6 cm³ |
| Condition on delivery | Single rod in standard length |
| Packaging unit | 1 |
| Recommended accessories | Cover cap 45x90x90, signal gray; Cover cap 45x90x90, black; Cover cap with hole 45x90x90, signal gray; Cover cap with hole 45x90x90, black |
| Hersteller-Nr | 3842537846 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 35.000000 |
| Lenght | 6070 mm |
| Zolltarifnummer | 76042100 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Positionserkennung | No |
