Strut Profile 30x60x60 Angled Cross-Section, 6070 mm, Anodized Aluminum - Bosch Rexroth 3842557248
Angled aluminum strut profile with a 30x60x60 cross-section and 8 open slots, 6070 mm long. The anodized finish and 30 mm modular dimension make it fully compatible with Bosch Rexroth profile system connectors and fasteners. Supplied as a single rod in standard length.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The strut profile 30x60x60 is an angled aluminum extrusion in the Bosch Rexroth 30 mm modular system. Eight open slots on all faces allow direct connection of standard T-slot nuts and connectors from the Rexroth profile range. The anodized natural finish provides corrosion resistance and a clean appearance for machine frames, guards, and enclosures where an angled cross-section is required.
- 8 open slots - full connectivity on every profile face
- Angled profile geometry suits corner joints without additional angle brackets
- Anodized aluminum - corrosion-resistant and ready to use without further surface treatment
- Compatible with cover caps 30x30 (signal gray or black) to close unused slots cleanly
Technical data
| Property | Value |
|---|---|
| Cross-section | 30x60x60 |
| Profile type | Angled |
| Length [L] | 6070 mm |
| Modular dimension | 30 mm |
| Open slots | 8 |
| Profile slot | 8 |
| Material | Aluminum, anodized |
| Color | Natural |
| Profile surface [A] | 8.2 cm² |
| Area moment of inertia X [lx] | 26.2 cm⁴ |
| Area moment of inertia Y [ly] | 26.2 cm⁴ |
| Moment of resistance X [Wx] | 7.6 cm³ |
| Moment of resistance Y [Wy] | 7.6 cm³ |
| Torsional moment of inertia [It] | 6.4 cm⁴ |
| Moment of torsion resistance [Wt] | 3.6 cm³ |
| Mass [m] | 2.2 kg |
| Weight (delivery unit) | 13.7 kg |
| Packaging unit | 1 |
| Condition on delivery | Single rod in standard length |
| Recommended accessories | Cover cap 30x30, signal gray; Cover cap 30x30, black |
| Weight | 13.7 kg |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | 3842557248 |
| Zolltarifnummer | 76042100 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Lenght | 6070 mm |
