Frame profile 45x45 mm in 6070 mm standard length, made from anodized aluminum with ESD compliance, for manual assembly systems and material carts. Supplied in packs of 20 profiles; profile slots 8 and 10 accept a wide range of Rexroth connectors and accessories. Recommended accessory: Bracket R40x43.
Frame Profile 45x45, 20 Pieces at 6070 mm, ESD, Anodized Aluminum - Bosch Rexroth 3842557942
BOSCH REXROTH
Original product
Net price (excl. VAT)
€4,047.61
Item
BRR-3842557942
Manufacturer no.
3842557942
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842557942
Country of originGermany
Customs tariff number76042100
ConditionNew
Artikel
BRR-3842557942
The Bosch Rexroth 45x45 mm frame profile is a structural component for manual production systems, material carts, and modular assembly workstations. The anodized aluminum construction meets ESD requirements and is delivered in a packaging unit of 20 pieces at a standard length of 6070 mm.
- ESD-compliant: anodized aluminum surface dissipates electrostatic charge reliably
- Two profile slot sizes (8 and 10) for broad accessory compatibility within the Rexroth modular system
- High bending stiffness: area moment of inertia lx 8.8 cm⁴ / ly 6.9 cm⁴
- Delivery unit of 20 pieces - cost-effective stocking for larger framing projects
- Recommended connecting accessory: Bracket R40x43
Technical data
| Property | Value |
|---|---|
| Profile cross-section | 45 x 45 mm |
| Length [L] | 6070 mm |
| Material | Aluminum, anodized |
| ESD | yes |
| Profile slot | 8, 10 |
| Profile surface [A] | 4.5 cm² |
| Area moment of inertia X [lx] | 8.8 cm⁴ |
| Area moment of inertia Y [ly] | 6.9 cm⁴ |
| Moment of resistance X [Wx] | 3.2 cm³ |
| Moment of resistance Y [Wy] | 2.3 cm³ |
| Mass [m] | 1.2 kg |
| Delivery unit | 20 pieces |
| Condition on delivery | Packaging unit in standard length |
| Recommended accessories | Bracket R40x43 |
| Weight (packaging unit) | 160.1 kg |
| Hersteller-Nr | 3842557942 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 160.100000 |
| Lenght | 6070 mm |
| Zolltarifnummer | 76042100 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Positionserkennung | No |
