Die-cast aluminum profile joint for connecting cable guide profiles or 40x120 / 40x120 5N profiles. Enables protected cable branches with high strength and stability. Secured with a central bolt M12 or S12.
Profile Joint 120x120 1/2 for Cable Guide Profiles - Bosch Rexroth 3842558246
BOSCH REXROTH
Original product
Net price (excl. VAT)
€94.18
Item
BRR-3842558246
Manufacturer no.
3842558246
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842558246
Country of originGermany
Customs tariff number76169990
ConditionNew
Artikel
BRR-3842558246
The profile joint 120x120 1/2 connects cable guide profiles as well as 40x120 and 40x120 5N profiles, allowing protected cable branches to be integrated cleanly into assembly lines and conveyor systems. The coated diecast aluminum construction combines high mechanical strength with low weight.
- High load capacity through diecast aluminum design
- Protected cable routing without exposed conductors
- Screw connection via central bolt M12x30-T50 (art. 3842530235) or S12x30-T50 (art. 3842530236)
- Positioning pin (required accessory) simplifies alignment during installation
Technical data
| Specification | Value |
|---|---|
| Type | Profile joint 120x120 1/2 |
| Material | Diecast aluminum, coated |
| Color | Signal gray RAL 7004 |
| Weight | 0.238 kg |
| Packaging unit | 1 piece |
| Required accessories | Positioning pin to facilitate assembly; central bolt M12x30-T50 (3842530235) or S12x30-T50 (3842530236) |
| Recommended accessories | Edge protector, cover cap, spacer for cover caps, caps |
| Hersteller-Nr | 3842558246 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.238000 |
| Zolltarifnummer | 76169990 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Positionserkennung | No |
