Lifting Column F3200-LIFT350 mm, 3200 N Compression Load, 9 mm/s - Bosch Rexroth 3842559959
The F3200-LIFT350 mm lifting column provides continuous height adjustment of workstations under high loads up to 3200 N compression force at a travel speed of 9 mm/s. Mounting is via face-side mounting plates or the integrated 10 mm slot. All lifting modules are ESD-enabled for use in electrostatic discharge-protected areas.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Bosch Rexroth F3200-LIFT350 mm lifting column is designed for continuous height adjustment of workstations under demanding compression loads. With a maximum compression load of 3200 N, a travel speed of 9 mm/s and a stroke length of 350 mm, it suits heavy-duty assembly and production workplaces.
- Maximum compression load 3200 N - supports substantial workplace superstructures
- Travel speed 9 mm/s - fast height adjustment even under full load
- Mounting via face-side mounting plates or integrated 10 mm slot
- Diagonal cover cap reduces crushing risk at the lifting mechanism
- ESD-enabled - mounting plates connected conductively, no additional bonding required
- Connection cable approx. 2 m included; cable exit selectable left or right
- Attachment bracket set available for lateral profile attachment (grid dimension 45 mm)
Technical data
| Parameter | Value |
|---|---|
| Type | F3200-LIFT350MM |
| Force F | 3200 N |
| Length [L] | 350 mm |
| Compression load [Fmax] | 3200 N |
| Tensile load [Fmax] | 1600 N |
| Tilting torque [My] | 250 Nm |
| Tilting torque [Mx] | 500 Nm |
| Speed | 9 mm/s |
| Maximum load version [Fmax] | 3200 N |
| Weight | 11.2 kg |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | 3842559959 |
| Zolltarifnummer | 84281020 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Lenght | 350 mm |
