ESD Cover Cap 40x45°, PP Black, Modular Dimension 40 mm - Bosch Rexroth 3842551017
Item BRR-3842551017
€1.70
Images are examples, some edited with AI. The technical data are authoritative. AI notice
Strut Profile 40x45°, ESD, Slot 10, Anodized Aluminum - Bosch Rexroth 3842529373
Bosch Rexroth
✓ Original product Brand new Made in Sweden
This strut profile with a 45-degree 40x45° cross-section provides diagonal bracing and stiffening in aluminum profile structures. It is ESD-capable and made of anodized aluminum, with profile slot 10 for connection within the 40 mm modular system. Supplied in the 6070 mm standard length in packaging units of 12.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Bosch Rexroth 40x45° strut profile provides diagonal bracing and stiffening in frames and machine structures built from aluminum profiles. It is intended for designers and system builders who need to stiffen frames and transfer loads at an angle.
- 45-degree 40x45° cross-section for diagonal bracing within the 40 mm modular system
- ESD-capable for applications requiring electrostatic discharge protection
- Profile slot 10 for connecting compatible connectors and profiles
- Made of anodized aluminum with a natural surface finish
Technical data
| Condition on delivery | Packaging unit in standard length |
|---|---|
| Cross-section | 40x45° |
| Profile type | 45 degrees |
| Dimensions | 40x40 |
| Modular dimension | 40 mm |
| Profile slot | 10 |
| Open slots | 2 |
| ESD | yes |
| Color | Natural |
| Material | Aluminum, anodized |
| Length [L] | 6070 mm |
| Delivery unit | 12 |
| Profile surface [A] | 6.8 cm² |
| Area moment of inertia in x-direction [Ix] | 9.9 cm⁴ |
| Area moment of inertia in y-direction [Iy] | 16.6 cm⁴ |
| Moment of resistance in x-direction [Wx] | 5 cm³ |
| Moment of resistance in y-direction [Wy] | 8.3 cm³ |
| Torsional moment of inertia [It] | 4.2 cm⁴ |
| Moment of torsion resistance [Wt] | 3.7 cm³ |
| Mass [m] | 1.8 kg |
| Recommended accessories | Cover cap 40x45°, signal gray or black |
| Weight | 172 kg |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | 3842529373 |
| Zolltarifnummer | 76042100 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Sweden |
| Lenght | 6070 mm |
