Gusset 40x40 designLINE Silver Set, Diecast Aluminum, ESD-Suitable - Bosch Rexroth 3842551603

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Gusset 40x40 designLINE Silver Set, Diecast Aluminum, ESD-Suitable - Bosch Rexroth 3842551603

Name: Gusset 40x40 designLINE Silver Set, Diecast Aluminum, ESD-Suitable - Bosch Rexroth 3842551603
Brand: Bosch Rexroth
SKU: BRR-3842551603
Price: 6.18 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Profile connector bracket for slot 10 systems in 40x40 mm format, designLINE variant in vibratory-ground and painted diecast aluminum, white aluminum (RAL 9006). ESD-suitable, supplied complete with 2x T-bolt M8x20 and 2x flange nut M8. Bending moment up to 145 Nm, torsional moment 35 Nm.

Net

€6.18

excl. VAT

Item BRR-3842551603

Manufacturer no. 3842551603

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Gusset 40x40 designLINE Silver Set creates rigid, visually consistent connections in slot 10 profile systems. The designLINE finish - vibratory-ground and painted diecast aluminum in white aluminum RAL 9006 - suits exposed joints in workstation and assembly structures. The set ships complete with all fastening hardware.

Bending moment 2: 145 Nm - high rigidity in the primary load direction
Bending moment 1: 55 Nm, torsional moment: 35 Nm
ESD-suitable for use in electrostatic discharge-protected workplaces
Painted surface in white aluminum RAL 9006 for a uniform appearance
Scope of delivery: bracket designLINE + 2x T-bolt M8x20 + 2x flange nut M8 (steel, galvanized)

Technical data

Attribute	Value
Dimensions	40x40 mm
Profile slot	10
Color	White aluminum (RAL 9006)
Bracket material	Diecast aluminum, vibratory ground and painted
Fastening material	Steel, galvanized
Bending moment 1	55 Nm
Bending moment 2	145 Nm
Torsional moment	35 Nm
ESD	yes
designLINE	yes
Fastening material included	2x T-bolt M8x20, 2x flange nut M8
Scope of delivery	Bracket designLINE incl. fastening material (FS)
Recommended accessories	Cover cap for bracket 40x40, signal gray (3842548854); cover cap for bracket 40x40, black (3842548855)
Weight	0.084 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	3842551603
Zolltarifnummer	76169910
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
ESD version	ESD (antistatic)
