Gusset 45x45 designLINE Silver Set, ESD-rated, Slot 10, RAL 9006 - Bosch Rexroth 3842551606

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Gusset 45x45 designLINE Silver Set, ESD-rated, Slot 10, RAL 9006 - Bosch Rexroth 3842551606

Name: Gusset 45x45 designLINE Silver Set, ESD-rated, Slot 10, RAL 9006 - Bosch Rexroth 3842551606
Brand: Bosch Rexroth
SKU: BRR-3842551606
Price: 6.24 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Diecast aluminum gusset for 45x45 designLINE profiles, vibratory ground and painted white aluminum (RAL 9006). ESD-rated, supplied complete with 2 T-bolts M8x25 and 2 flange nuts M8. Bending moment up to 160 Nm for rigid frame and workstation structures.

Net

€6.24

excl. VAT

Item BRR-3842551606

Manufacturer no. 3842551606

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Gusset 45x45 Silver Set is part of the Bosch Rexroth designLINE range, providing a form-fit, ESD-rated connection for 45x45 aluminum profiles. Made from diecast aluminum, vibratory ground and painted in white aluminum (RAL 9006), it integrates cleanly into designLINE workstations and machine frames where appearance and electrostatic safety both matter.

Bending moment 1: 60 Nm, bending moment 2: 160 Nm - suitable for load-bearing frame joints
ESD-rated: safe for use in electrostatically sensitive production environments
Complete set: 2x T-bolt M8x25 and 2x flange nut M8 in galvanized steel included
Recommended accessory: sliding block, offset (3842523593) for optimum force transfer
Fits profile slot 10 of the 45x45 profile series

Technical data

Property	Value
Dimensions	45x45
Profile slot	10
Bending moment 1	60 Nm
Bending moment 2	160 Nm
Material	Diecast aluminum, vibratory ground and painted
Fastening material	Steel, galvanized
Color	White aluminum (RAL 9006)
ESD	Yes
designLINE	Yes
Scope of delivery	Bracket designLINE, 2x T-bolt M8x25, 2x flange nut M8
Weight	0.111 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	3842551606
Zolltarifnummer	76169910
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
ESD version	ESD (antistatic)
