The product may differ from the illustration
Linear slide trolley for Bosch Rexroth aluminum profiles with 60 mm width and profile slot 10. Compression load up to 1250 N, sliding speed up to 12 m/min, anodized aluminum construction. Includes spacer washer for tolerance compensation between trolley and profile.
EcoSlide-Wagen 45x60x80 für Profilbreite 60 mm - Bosch Rexroth 8981535478
BOSCH REXROTH Original product
Net price (excl. VAT)
€54.34 €45.66
excl. Shipping Cost
Item BRR-8981535478
Manufacturer no. 8981535478
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.8981535478
Country of originUnited States
Customs tariff number76169990
ConditionNew
Artikel
BRR-8981535478
The EcoSlide trolley 45x60x80 provides smooth linear movement on aluminum profiles with 60 mm width and profile slot 10. The anodized aluminum body with integrated spacer washer compensates manufacturing tolerances between trolley and profile, simplifying assembly. When using a clamping lever, the corresponding hole in the trolley must be drilled out to 9 mm.
- Compression load up to 1250 N and tensile load up to 625 N for reliable linear guidance
- Sliding speed up to 12 m/min for dynamic handling applications
- Torque around x axis max. 40 Nm, around z axis max. 150 Nm
- Anodized aluminum - corrosion-resistant and lightweight
- Spacer washer included for tolerance compensation, simplifying installation
Technical data
| Specification | Value |
|---|---|
| Dimensions (L x W x H) | 45 x 60 x 80 mm |
| Profile slot | 10 |
| Profile width | 60 mm |
| Compression load Fmax | 1250 N |
| Tensile load Fmax | 625 N |
| Maximum sliding speed | 12 m/min |
| Torque around x axis Mmax | 40 Nm |
| Torque around z axis Mmax | 150 Nm |
| Material | Aluminum, anodized |
| Weight | 0.329 kg |
| Packaging unit | 1 piece |
| Recommended accessories | N10 flat slider and flat lockable, spacer washer, clamping lever, N10 sliding block |
| Hersteller-Nr | 8981535478 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | United States |
| Weight | 0.329000 |
| Zolltarifnummer | 76169990 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
