Closed euro container with interlocking system 80 x 60 x 52 cm - Auer EG VL 86/52

The Auer EG VL 86/52 is a closed stacking euro container made of polypropylene, measuring 80 x 60 x 52 cm on the outside and holding 228 litres. The interlocking system along the long sides locks stacks in place and makes the container a matching footprint for euro transport dollies in the 80 x 60 format.

Benefits

• 228 litres of usable volume on a compact 80 x 60 cm euro footprint
• Interlocking system on the long side secures stacks by form fit
• Reinforced, closed base for high load capacity and clean handling
• Usable internal stacking height of 49.2 cm for bulky parts
• Durable PP, temperature resistant and largely chemical resistant

Technical data

• External dimensions L x W x H: 80 x 60 x 52 cm
• Internal dimensions L x W x H: 76.7 x 56.7 x 50.5 cm
• Usable internal stacking height: 49.2 cm
• Stacking height: 50.8 cm
• Volume: 228 litres
• Side design: closed
• Base design: reinforced, closed
• Interlocking system: long side
• Front-side grips: open
• Long-side grips: closed
• Material: PP
• Colour: silver grey similar to RAL 7001
• Weight: 7.37 kg

Applications

The container suits warehousing, order picking and in-plant transport, for example for raw parts, assemblies or semi-finished goods. Combined with a Maxi HD transport dolly it forms a rolling transport unit without a separate pallet.

Note: slight colour variations cannot be fully avoided due to the raw material.
