LED machine luminaire MACH LED PLUS.seventy MQAL 12 SD, 24 V DC, 500 lm, 370 mm, through-wired - Waldmann 113046000-00580696

Targeted light over a short distance comes from the MACH LED PLUS.seventy MQAL 12 SD: 370 mm long, around 500 lm at 5 W. The Eco fitting is often sufficient to achieve comparable illumination when replacing conventional tube luminaires, with a luminous efficiency of 100 lm/W. It connects to the machine control voltage of 18-30 V DC and needs no control gear (protection class III). Being through-wired with a connection box, several luminaires can be daisy-chained electrically.

Benefits

• Efficient: 100 lm/W, around 500 lm at only 5 W power consumption
• Housing of clear anodised aluminium with borosilicate glass, vibration-proof at 10-55 Hz and shock-proof up to 50 g
• Outer diameter of 70 mm for easy replacement of traditional tube luminaires
• Suitable for ambient temperatures from -10 to 60 °C
• 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

• Small machine interiors, test stations and assembly stations
• Conversion of conventional tube luminaires to LED
• Continuous light lines along production and assembly lines

Installation and accessories

• Mounting with L-angle, clamp or luminaire bracket (adjustable +/-30°, as a set +/-65°, with rubber profile) from the accessories
• Mains connection via built-in plug series 763, M12, 4-pin, A-coded, plus connection box for the next luminaire
• Matching accessories: connection sockets, connecting plugs, connection cables 3 m or 7 m (5 x 0.5 mm²) and protective cap set
