LED arm-mounted luminaire ALD 1300/950/D, 1400 lm, CRI ≥ 90, 5000 K, with table clamp - Waldmann 113686000-00815669

In inspection and assembly work, the colours of cables, components or surfaces must be identified reliably. The ALD 1300/950/D delivers light with CRI ≥ 90 and R9 ≥ 50 at 5000 K, approx. 1400 lm from 18 W (around 93 lm/W). The spring-balanced arm with head joint places the light right above the workpiece, and dimming is continuous via the multi-function switch.

Benefits

• CRI ≥ 90 with R9 ≥ 50: reds and colour codes are rendered true to life
• Approx. 1400 lm at 18 W, around 93 lm/W, colour tolerance < 3 SDCM
• Touch DIM: switching and continuous dimming via the multi-function switch in the head
• Spring-balanced arm of clear anodised aluminium profile for easy, precise positioning
• Diffuser with 86° beam angle and UGR ≤ 25
• Plug-in power supply 100-240 V with CEE 7/XVI, BS 1363 A and NEMA 1-15P plugs

Applications

• Assembly workstations
• Inspection and quality control stations
• Laboratory and dental workstations

Installation and accessories

• Mounting via Ø 16 mm spigot, table clamp included
• Mains lead approx. 3.2 m with electronic plug-in ballast, protection class II with plug-in power supply
