LED machine luminaire MACH LED PLUS.seventy MQAL 12 S, 24 V DC, cable gland, IP67

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED machine luminaire MACH LED PLUS.seventy MQAL 12 S, 24 V DC, cable gland, IP67 - Waldmann 113709000-00804709

Name: LED machine luminaire MACH LED PLUS.seventy MQAL 12 S, 24 V DC, cable gland, IP67 - Waldmann 113709000-00804709
Brand: Waldmann
SKU: WAL-113709000-00804709
Price: 240.82 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

LED machine luminaire with 70 mm diameter for 24 V DC, with screwed cable gland for fixed wiring. Approx. 500 lm at 5 W, IP67 protection, mounted by thread or luminaire bracket. For machines where the lead is wired directly into the terminal box. Waldmann grants a 20-year manufacturer's warranty on this luminaire.

Net

€240.82

excl. VAT

Item WAL-113709000-00804709

Manufacturer no. 113709000-00804709

Question about this item

Datasheet (PDF) User manual 7 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

If the luminaire lead is wired directly into the machine terminal box, the version with screwed cable gland is the right choice. The MACH LED PLUS.seventy MQAL 12 S runs on 24 V DC without control gear and delivers approx. 500 lm of neutral white light at 5000 K for approx. 5 W.

Benefits

Screwed cable gland for fixed wiring at 20-28 V DC
Mounting via M40 x 1.5 thread or luminaire bracket from the accessories
IP67, protection class III, ambient temperature -10 to 45 °C
Clear borosilicate glass screen, glare control via optical film, UGR ≤ 25
Vibration-proof at 10 to 55 Hz (amplitude 0.35 mm), shock-resistant up to 50 g
20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

Machine tools and special machinery with fixed wiring
Woodworking machines
Inspection stations in production
Replacement of conventional 70 mm tube luminaires

Installation and accessories

One-sided fastening via M40 x 1.5 thread
Black luminaire bracket available as accessory for flexible alignment

Technical data

Manufacturer part no.	113709000-00804709
Order no.	00804709
EAN	4013330049805
Connected load	20-28 V, DC
Control gear	Without
Power consumption	approx. 5 W
Luminous flux	approx. 500 lm
Luminous efficiency	approx. 100 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 5000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, Symmetric, approx. 100 %
Beam angle	80°
Glare control	optical film
Light source	LED
Chromaticity tolerance LED	< 4 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 24,000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 25
System of protection/Class	IP 67, III
Technology	Switchable
Operation	External
Housing	Aluminium, Anodised, Aluminium coloured anodised
Light source cover	Borosilicate, Clear
Mains lead	Connector, Series 2061
Design	mounted version
Fastening	Lamp bracket (accessory), Thread M40 x 1.5
Ambient temperature min./max	-10 °C, 45 °C
Weight without/incl. packaging	0.73 kg / approx. 1.3 kg
Dimensions (dimensional drawing)	220 mm
Packaging dimensions	425 mm, approx. 82 mm, 86 mm
Manufacturer's warranty	20 years (Waldmann general warranty terms)
Weight	1.3 kg
Manufacturer	Waldmann
Hersteller-Nr	113709000-00804709
Zolltarifnummer	94054239
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Verkaufseinheit	1 Stück
Colour	Silver
Farbe	Aluminiumfarben
Lichtstrom (Lumen)	500 lm
Power	5 W
Farbwiedergabe (Ra)	Ra 80
Abstrahlwinkel	80°
Operating voltage	20-28 V
Series	MACH LED PLUS.seventy
Protection rating	IP67
