LED machine luminaire MACH LED PLUS.seventy MQAL 12 S, 24 V DC, M12 A-coded, IP67, 500 lm

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED machine luminaire MACH LED PLUS.seventy MQAL 12 S, 24 V DC, M12 A-coded, IP67, 500 lm - Waldmann 113709000-00804711

Name: LED machine luminaire MACH LED PLUS.seventy MQAL 12 S, 24 V DC, M12 A-coded, IP67, 500 lm - Waldmann 113709000-00804711
Brand: Waldmann
SKU: WAL-113709000-00804711
Price: 276.34 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

Short LED machine luminaire, 70 mm diameter and 220 mm long, for 24 V DC with potted M12 connector, A-coded. Approx. 500 lm at 5 W and approx. 100 lm/W, IP67 protection. For machine tools and machining centres. Waldmann grants a 20-year manufacturer's warranty on this luminaire.

Net

€276.34

excl. VAT

Item WAL-113709000-00804711

Manufacturer no. 113709000-00804711

Question about this item

Datasheet (PDF) User manual 7 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Inside the working area of a machine tool, a luminaire has to withstand coolant, chips and vibration. The MACH LED PLUS.seventy MQAL 12 S plugs straight into the 24 V machine supply and delivers approx. 500 lm of neutral white light at 5000 K for only approx. 5 W, equal to approx. 100 lm/W.

Benefits

Plug-and-play via M12 connector, 4-pole, A-coded (series 763), no control gear at 20-28 V DC
Outer diameter 70 mm and length 220 mm, suited as a replacement for classic tube luminaires
IP67 protection, protection class III, ambient temperature -10 to 45 °C
Anodised aluminium housing, clear borosilicate glass cover
Vibration-proof at 10 to 55 Hz (amplitude 0.35 mm), shock-resistant up to 50 g
20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

Lathes, milling machines and machining centres
Woodworking machines
Integrated production and inspection systems
Retrofitting machines with 24 V control voltage

Installation and accessories

One-sided fastening via M40 x 1.5 thread
Matching accessories: M12 connection socket (A-coded) or M12 connection cable with 3 m or 7 m lead (5 x 0.5 mm²)

Technical data

Manufacturer part no.	113709000-00804711
Order no.	00804711
EAN	4013330049843
Connected load	20-28 V, DC
Control gear	Without
Power consumption	approx. 5 W
Luminous flux	approx. 500 lm
Luminous efficiency	approx. 100 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 5000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, Symmetric, approx. 100 %
Beam angle	80°
Glare control	optical film
Light source	LED
Chromaticity tolerance LED	< 4 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 24,000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 25
System of protection/Class	IP 67, III
Technology	Switchable
Operation	External
Housing	Aluminium, Anodised, Aluminium coloured anodised
Light source cover	Borosilicate, Clear
Mains lead	Connector, Series 763 4pol (A cod) M12
Design	mounted version
Fastening	Thread M40 x 1.5
Ambient temperature min./max	-10 °C, 45 °C
Weight without/incl. packaging	0.74 kg / approx. 1.3 kg
Dimensions (dimensional drawing)	220 mm
Packaging dimensions	425 mm, approx. 82 mm, 86 mm
Manufacturer's warranty	20 years (Waldmann general warranty terms)
Weight	1.3 kg
Manufacturer	Waldmann
Hersteller-Nr	113709000-00804711
Zolltarifnummer	94054239
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Verkaufseinheit	1 Stück
Colour	Silver
Farbe	Aluminiumfarben
Lichtstrom (Lumen)	500 lm
Power	5 W
Farbwiedergabe (Ra)	Ra 80
Abstrahlwinkel	80°
Operating voltage	20-28 V
Series	MACH LED PLUS.seventy
Protection rating	IP67
