LED arm-mounted luminaire TANEO TND 1400/930-965/D, 1500 lm, tunable white, prism aperture 75° - Waldmann 113735000-00810081

With shiny components and at screen-based inspection stations, light without distracting reflections matters. The TANEO TND 1400/930-965/D with prism aperture concentrates approx. 1500 lm into 75°, limits luminance to ≤ 12,000 cd/m² and switches between 3000 and 6500 K.

Benefits

• Adjustable white: 3000, 4000, 5000 or 6500 K selectable at the switch, colour rendering CRI ≥ 90 and R9 ≥ 50 at every setting.
• Structured cover with prism aperture and 75° beam angle focus the light on the task, luminance L65 ≤ 12,000 cd/m², UGR ≤ 25.
• Approx. 1500 lm at approx. 23 W and approx. 75 lm/W, enough light for detailed work right under the head.
• Spring-balanced arm: the head can be positioned with one hand and stays where it is set.
• 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

• Workstations handling changing materials and surfaces
• Assembly and test stations in shift operation
• Laboratory and analysis

Installation and accessories

• Fastening: spigot Ø 16 mm, screw-down flange, table clamp as accessory
• Mains 100-240 V, 50/60 Hz via power supply (24 V secondary), lead approx. 3.4 m with mains plug CEE 7/VII
• Matching table clamps: TK 1/45 (0-45 mm), TK 1/65 (0-65 mm), TK 1/165 (95-165 mm), table clamp 65-135 mm
