LED arm-mounted luminaire TANEO TND 2100/950/D, 2000 lm, 5000 K, 30 W - Waldmann 113736000-00809767

Fine solder joints, small threads and dark surfaces need a lot of light on the work surface. The TANEO TND 2100/950/D provides approx. 2000 lm of 5000 K neutral white light at approx. 30 W, which is approx. 76 lm/W, spread widely across the workpiece with a 110° beam.

Benefits

• Approx. 2000 lm at approx. 30 W and approx. 76 lm/W, enough light for detailed work right under the head.
• Neutral white 5000 K, CRI ≥ 90 and R9 ≥ 50 with < 3 SDCM colour tolerance keep wire colours, solder joints and markings easy to tell apart.
• Matt cover and 110° beam angle give a wide, even light field, also on larger workpieces.
• Spring-balanced arm: the head can be positioned with one hand and stays where it is set.
• 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

• Precision assembly and test stations
• Electronics manufacturing and soldering stations
• Watchmaking and precision mechanics
• Laboratory

Installation and accessories

• Fastening: spigot Ø 16 mm, screw-down flange, table clamp as accessory
• Mains 100-240 V, 50/60 Hz via power supply (24 V secondary), lead approx. 3.4 m with mains plug CEE 7/VII
• Matching table clamps: TK 1/45 (0-45 mm), TK 1/65 (0-65 mm), TK 1/165 (95-165 mm), table clamp 65-135 mm
• Series accessories: TANEO wall bracket, magnifier 3.5 dpt (ø 132 mm, plastic lens), magnifier 4 dpt (100 x 50 mm, glass lens)
