LED machine luminaire LINURA.maxx LMA 2500/850/BS, 21 W, 2750 lm, 755 mm, IO-Link - Waldmann 114122000-00804058
Waldmann
✓ Original product Brand new Made in Germany
Slim surface-mounted LED luminaire for machines with 2750 lm, 21 W and a length of 755 mm, IP 54 and 22-26 V DC via M12. The IO-Link version dims continuously and reports operating data to the controller. Designed for the interior of machine tools, longer workbenches and conveyor sections. Waldmann grants a 20-year manufacturer's warranty on this luminaire.
Net
excl. VAT
€233.19
Item
WAL-114122000-00804058
Manufacturer no.
114122000-00804058
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For machine tools and longer workbenches, the LINURA.maxx LMA 2500/850/BS delivers approx. 2750 lm of neutral white 5000 K light from 21 W in a housing 755 mm long. Its IO-Link interface makes it continuously dimmable and lets the machine control address it directly.
Benefits
- 2750 lm at 21 W, approx. 130 lm/W: plenty of light per watt and little heat at the workpiece
- Continuously dimmable via IO-Link bus: brightness and light patterns such as flashing or breathing are set directly by the PLC
- Diagnostics via IO-Link: overtemperature, operating hours and remaining service life can be read out, overvoltage is reported
- 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)
Applications
- Machine tools
- Longer workbenches
- Conveyor sections and transfer stations
- Automated plants with IO-Link architecture
Installation and accessories
- Brackets included, adjustable by +/- 75°, for aluminium system and control cabinet profiles
- Mains connection via integrated M12 built-in plug M12-A-5
- Accessories: M12 connection cable (3 m or 7 m), M12 connection socket and plug, holder with heat-shrinkable sleeve for screwing on
Technical data
| Manufacturer item no. | 114122000-00804058 |
|---|---|
| Order number | 00804058 |
| Connected load | 22-26 V DC |
| Work equipment | Without |
| Power consumption | approx. 21 W |
| Luminous flux | approx. 2750 lm |
| Luminous efficiency | approx. 130 lm/W |
| Light type/-color | Neutral white |
| Colour temperature | approx. 5000 K |
| Color rendering index | CRI ≥ 80 |
| Light distribution | Direct, approx. 97 % |
| Beam angle | 85° |
| Glare control | Optics |
| Light source | LED |
| Chromaticity tolerance LED | < 4 SDCM |
| At-risk group | RG0/1 |
| System of protection/Class | IP 54, III |
| Technology | Continuously dimmable, IO-Link Bus |
| Operation | External |
| Housing | Aluminium/plastic, Anodised, painted, Aluminium coloured anodised |
| Light source cover | Acrylic (PMMA), Satine |
| Mains lead | Built-in plug, M12-A-5 |
| Design | mounted version |
| Fastening | Bracket |
| Ambient temperature min./max | 5 °C / 50 °C |
| Decorative contrast side parts | Natural silver anodised |
| Weight without/incl. packaging | 0.329 kg (incl. packaging approx. 0.7 kg) |
| Dimensions (dimensional drawing) | A=755 mm. C=717.5 +/- 22.5 mm |
| Packaging dimensions | 843 x 100 x 88 mm |
| EAN | 4013330124601 |
| Special features | IO-Link |
| Manufacturer's warranty | 20 years (Waldmann general warranty terms) |
| Weight | 0.7 kg |
| Manufacturer | Waldmann |
| Hersteller-Nr | 114122000-00804058 |
| Zolltarifnummer | 94054239 |
| GPSR manufacturer information | WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Verkaufseinheit | 1 Stück |
| Colour | Silver |
| Farbe | Aluminiumfarben |
| Steuerung / Betriebsgerät | Dimmable |
| Lichtstrom (Lumen) | 2750 lm |
| Power | 21 W |
| Farbwiedergabe (Ra) | Ra 80 |
| Abstrahlwinkel | 85° |
| Overall length [mm] | 755 |
| Operating voltage | 22-26 V |
| Series | LINURA.maxx |
| Protection rating | IP54 |
