System Lamp SL12LED ECO WIDE, 550 lx, 5000 K - Bosch Rexroth 3842559395
Bosch Rexroth
✓ Original product Brand new Made in Hungary
The SL12LED ECO WIDE is an energy-efficient LED workstation lamp for benches up to 1600 x 600 mm. It delivers 550 lx at 5000 K with a 60° wide-angle matte optic for glare-free, even illumination. Supplied with 10 mm slot mounting hardware and a 16 cm connecting cable with GST plug; suitable for 120-240 V / 50-60 Hz installations (UL/CSA listed).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The SL12LED ECO WIDE provides glare-free LED task lighting for assembly workstations up to 1600 x 600 mm, combining high light output with low energy draw and a 50000-hour service life. The matte wide optic spreads light evenly across the full work surface, reducing eye fatigue during extended production shifts.
- 550 lx illuminance at 1.25 m measuring distance (workstation 1600 x 600 mm)
- 5000 K daylight colour temperature for accurate colour recognition and sustained concentration
- Luminous efficiency approx. 140 lm/W; energy efficiency value 11.5 ± 0.5
- 50000 h rated service life - minimal maintenance in continuous industrial use
- IP20 protection (DIN EN IEC 60529); UL/CSA conformity; wide voltage range 120-240 V / 50-60 Hz
- Painted sheet-steel housing; mass 2.65 kg
- Mounts in 10 mm profile slot or on the underside of a profile rail; fastening kit included
Technical data
| Parameter | Value |
|---|---|
| Illuminance | 550 lx |
| Colour temperature | 5000 K |
| Beam angle | 60° |
| Luminous efficiency | approx. 140 lm/W |
| Energy efficiency | 11.5 ± 0.5 |
| Service life | 50000 h |
| Voltage / frequency | 120-240 V / 50 Hz; 60 Hz |
| Protection class | IP20 (DIN EN IEC 60529) |
| Conformity | UL, CSA |
| Housing | Sheet steel, painted |
| Mass | 2.65 kg |
| Gross weight | 2.8 kg |
| Scope of delivery | Incl. fastening kit (10 mm slot), connecting cable 16 cm with GST plug |
| Required accessories | Mains cable or connecting cable |
| Recommended accessories | H-distributor POWER (230 V) or T-plug |
| Measuring conditions | Workstation 1600 x 600 mm, measuring distance worktop to lamp 1.25 m |
| Weight | 2.8 kg |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | 3842559395 |
| Zolltarifnummer | 94054239 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Hungary |
| Certification | IEC 60529 |
