SL12LED Basic System Lamp for Assembly Profiles - Bosch Rexroth 3842563246

Images are examples, some edited with AI. The technical data are authoritative. AI notice

SL12LED Basic System Lamp for Assembly Profiles - Bosch Rexroth 3842563246

Name: SL12LED Basic System Lamp for Assembly Profiles - Bosch Rexroth 3842563246
Brand: Bosch Rexroth
SKU: BRR-3842563246
Price: 180.85 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Hungary

LED work-area lamp designed for tool-free mounting in 10 mm slot-based aluminum profile systems. Daylight white (5000 K), 60,000 h service life, ESD-compatible when used with the Plate or Bracket fastening kit. Requires a separate DIM-Box power supply with stepless dimming (0-100 %).

Net

€180.85

excl. VAT

Item BRR-3842563246

Manufacturer no. 3842563246

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The SL12LED Basic system lamp is a compact LED luminaire for direct snap-in mounting in the 10 mm slots of aluminum profile workstation systems. A single GST mini output allows connection of one additional lamp in series. The anodized aluminum housing (IP20) provides reliable durability in continuous industrial use.

Daylight white 5000 K - uniform, glare-reduced illumination for assembly and inspection workstations
60,000 h rated service life - low maintenance overhead in multi-shift operation
ESD-compatible - safe use at electrostatically protected workstations (ESD fastening kit required)
Stepless dimming (0-100 %) via the ergonomic rotary control on the DIM-Box
Fast slot mounting - fastening kit for 10 mm slot included in scope of delivery
Low-voltage operation <60 V DC SELV - enhanced personnel safety per IEC 60364-4-41

Technical data

Parameter	Value
Color temperature	5000 K
Service life	60,000 h
Supply voltage	<60 V DC SELV
Protection class	IP20 (DIN EN IEC 60529)
Housing material	Aluminum, anodized
ESD compatibility	Yes (with Plate or Bracket fastening kit)
Scope of delivery	Includes fastening kit for 10 mm slot
Required accessories	Power supply DIM-Box, mains cable, connection cable
Outputs	1 x GST mini (for one additional SL12 Basic)
Mass	0.6 kg
Weight (incl. packaging)	0.7 kg
Conformity	UL, CSA
Weight	0.7 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	3842563246
Zolltarifnummer	94054239
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Hungary
Certification	IEC 60364-4-41, IEC 60529
