Swivel mounting 180°, galvanized steel, slot 8/10, ESD - Bosch Rexroth 3842538275

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Swivel mounting 180°, galvanized steel, slot 8/10, ESD - Bosch Rexroth 3842538275

Name: Swivel mounting 180°, galvanized steel, slot 8/10, ESD - Bosch Rexroth 3842538275
Brand: Bosch Rexroth
SKU: BRR-3842538275
Price: 18.40 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Articulated swivel mounting for joining aluminum profiles with a continuous 180° swivel range. Galvanized steel, ESD-capable and suited to profile slot 8 and 10. The set position is locked tool-free with the clamping lever.

Net

€18.40

excl. VAT

Item BRR-3842538275

Manufacturer no. 3842538275

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The swivel mounting 180° joins two aluminum profiles in an articulated way and allows continuous pivoting over 180°. It is suited to building workstations and material levels in manual production systems.

180° swivel range for flexible alignment of attached components
Clamping lever with disk locks the set position without tools
ESD-capable for use in electrostatically protected areas
Joins profile slot 8 to slot 8 or slot 10 (P1/P2: 8/8, 8/10)

Technical data

Profile slot	8; 10
Profile slot P1/P2	8/8, 8/10
ESD	yes
Material	Steel, galvanized
Material information	Swivel mounting: steel, galvanized; clamping lever: diecast zinc, black plastic coated
Scope of delivery	Incl. fastening material (FS), clamping lever with disk and swivel-in sliding block with spring
Fastening material	1x cylinder head screw ISO4762-M8x12, 2x sliding block groove 8 M8 suspended, 2x cylinder head screw ISO4762-M6x16, 2x T-nut groove 10 M6, 2x cylinder head screw ISO4762-M6x12, 1x T-nut groove 8 M6, 2x washer DIN125-A6,4, 1x washer DIN9021-8,4
Packaging unit	1
Weight	0.408 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	3842538275
Zolltarifnummer	73269098
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
ESD version	ESD (antistatic)
Norm	DIN 125, DIN 9021-8, DIN EN ISO 4762
