Cubic Joint 20/3 Set, Slot 6, ESD, Diecast Aluminum - Bosch Rexroth 3842549860
Bosch Rexroth
✓ Original product Brand new Made in Germany
Three-outlet cubic joint for Rexroth 20x20 mm slot-6 profiles. The diecast aluminum body creates a conductive connection between profiles, making it suitable for ESD-protected assembly workstations. The set includes the cubic connector, three countersunk screws S6x16, and a signal-gray cover cap D12.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Cubic Joint 20/3 connects three Rexroth aluminum profiles 20x20 mm (slot 6) at a single node point, suited to ESD-conscious workstation frames and structural assemblies. The diecast aluminum housing creates a conductive connection between profiles; the PP cover caps included in the set are not ESD-compatible and should be replaced with suitable caps in ESD-critical areas.
- Three outlets for compact corner and cross connections without additional angle brackets
- Diecast aluminum with conductive connection - suitable for ESD-protection zones
- Bending moment 3P: 23 Nm for stable frame structures
- Complete set: 3x countersunk screw S6x16 and cover cap D12 signal gray (PP) included
- Signal gray color - consistent with the Rexroth 20 profile series
Technical data
| Attribute | Value |
|---|---|
| Profile dimensions | 20x20 mm |
| Profile slot | 6 |
| Number of outlets | 3 |
| Bending moment 3P | 23 Nm |
| Material | Diecast aluminum |
| Fastening material | Steel, galvanized |
| Scope of delivery | Cubic connector (standard), 3x countersunk screw S6x16, cover cap D12 signal gray (PP) |
| ESD | Yes (conductive connection; cover caps not ESD-compatible) |
| Color | Signal gray |
| Recommended accessories | Cover cap D12, black (PP) |
| Weight | 0.021 kg |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | 3842549860 |
| Zolltarifnummer | 76169910 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | ESD (antistatic) |
