EcoSlide Trolley 45x45x160 mm, Anodized Aluminum, Profile Slot 10 - Bosch Rexroth 8981535324

Name: EcoSlide Trolley 45x45x160 mm, Anodized Aluminum, Profile Slot 10 - Bosch Rexroth 8981535324
Brand: Bosch Rexroth
SKU: BRR-8981535324
Price: 56.77 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in United States

The EcoSlide trolley 45x45x160 is an anodized aluminum slide carriage for 45 mm profiles with slot size 10. It handles compression loads up to 2500 N and sliding speeds up to 12 m/min. A built-in spacer washer compensates tolerances between trolley and profile for fast, precise assembly.

Net

€56.77

excl. VAT

Item BRR-8981535324

Manufacturer no. 8981535324

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Bosch Rexroth EcoSlide trolley 45x45x160 is an anodized aluminum carriage designed for smooth linear travel along 45 mm aluminum profiles with profile slot 10. It is well suited for assembly workstations, fixtures, and handling units where repeatable, tool-free positioning is required.

Compression load up to 2500 N and tensile load up to 1250 N for reliable guidance under varying forces
Maximum sliding speed of 12 m/min supports efficient manual or guided adjustment cycles
Integrated spacer washer compensates manufacturing tolerances between trolley and profile
Anodized aluminum construction: corrosion-resistant and lightweight at 0.612 kg
To use with a clamping lever, the corresponding bore in the trolley must be drilled out to 9 mm

Technical data

Parameter	Value
Dimensions (L x W x H)	45 x 45 x 160 mm
Profile slot	10
Profile width	45 mm
Material	Aluminum, anodized
Compression load Fmax	2500 N
Tensile load Fmax	1250 N
Torque around x axis Mmax	80 Nm
Torque around z axis Mmax	200 Nm
Maximum sliding speed	12 m/min
Packaging unit	1
Weight	0.612 kg
Recommended accessories	N10 flat slider, N10 flat lockable slider, spacer washer, clamping lever, N10 sliding block
Manufacturer	Bosch Rexroth
Hersteller-Nr	8981535324
Zolltarifnummer	84313900
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	United States
