LED machine luminaire LINURA.edge LEA 1000/YEL/S, yellow light, 1500 lm, 1455 mm - Waldmann 114109000-00804413

Large machine openings and long equipment fronts in photolithography can be lit with one single long luminaire. The LINURA.edge LEA 1000/YEL/S is 1455 mm long, provides approx. 1500 lm of yellow light at 30 W and runs on 22-26 V DC. The yellow light is intended for photochemically sensitive processes, so that photoresists are not exposed unintentionally.

Benefits

• Yellow light without UV content according to the manufacturer, luminous flux approx. 1500 lm at 30 W
• Length 1455 mm (dimension C 1425 mm +/- 15 mm) for mounting on machines and profiles
• IP54 and protection class III, anodised aluminium housing with satin acrylic cover, ambient temperature 5-40 °C
• Direct light with approx. 98 % direct component and 89° beam angle onto the work surface
• Plug-and-play via M12 connector (A-coded, 5-pole), 22-26 V DC without separate control gear
• 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

• Large machine openings and long equipment fronts in photolithography
• Pharmaceutical processes with light-sensitive substances
• Microelectronics with photoresist processes

Installation and accessories

• Luminaire bracket adjustable by +/- 60°, included according to the manufacturer, for aluminium system and control cabinet profiles
• Connection via M12-A-5 plug, compatible with 3 m and 7 m connection cables (5 x 0.5 mm²) and the M12 connection socket
• Switching via external controls: capacitive contact sensor or LDS/ST distance sensor looped into the supply line
• Optional holders with black heat-shrink sleeve for screwing on or with magnet
