LED arm-mounted luminaire TANEO TND 700/950/D, 700 lm, 5000 K, 75°, table base - Waldmann 113734000-00809716

Inspecting or assembling small parts at a single station calls for light exactly where the hands are working. The TANEO TND 700/950/D directs approx. 700 lm of 5000 K neutral white light through a structured cover into a 75° beam, and its table base needs no installation at all.

Benefits

• Structured cover and 75° beam angle focus the light on the task, luminance L65 ≤ 12,000 cd/m², UGR ≤ 25.
• Neutral white 5000 K, CRI ≥ 90 and R9 ≥ 50 with < 3 SDCM colour tolerance keep wire colours, solder joints and markings easy to tell apart.
• Touch DIM: multi-function switch in the luminaire head for switching and continuous dimming right at the light source.
• Table base: set it down and plug it in. No drilling or clamping, the luminaire moves with the workstation.
• Approx. 700 lm at approx. 10 W secondary and approx. 70 lm/W, enough light for detailed work right under the head.
• 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

• Precision assembly and test stations
• Electronics manufacturing and soldering stations
• Watchmaking and precision mechanics
• Laboratory

Installation and accessories

• Fastening: table base
• Mains 100-240 V, 50/60 Hz via power supply (24 V secondary), lead approx. 3 m with mains plug CEE 7/XVI, BS 1363, NEMA 1-15P
• Series accessories: TANEO wall bracket, magnifier 3.5 dpt (ø 132 mm, plastic lens), magnifier 4 dpt (100 x 50 mm, glass lens)
