LED arm-mounted luminaire TANEO TND 700/D50/D, 550 lm, D50 standard light, CRI 95, table base - Waldmann 113734000-00810077

When judging the colour of samples, labels or plastic parts, light quality determines the result. The TANEO TND 700/D50/D provides D50 standard light with CRI ≥ 95 and R9 ≥ 85 at approx. 550 lm, and its table base makes it ready for use at the inspection station straight away.

Benefits

• D50 standard light at approx. 5000 K with CRI ≥ 95 and R9 ≥ 85 renders hues and reds reliably for colour matching and visual inspection.
• Matt cover and 110° beam angle give a wide, even light field, also on larger workpieces.
• Touch DIM: multi-function switch in the luminaire head for switching and continuous dimming right at the light source.
• Table base: set it down and plug it in. No drilling or clamping, the luminaire moves with the workstation.
• Approx. 550 lm at approx. 14 W and approx. 45 lm/W, enough light for detailed work right under the head.
• 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

• Quality assurance and incoming inspection
• Surface and paint inspection
• Printing, textile and plastics processing
• Colour matching and sample checks

Installation and accessories

• Fastening: table base
• Mains 100-240 V, 50/60 Hz via power supply (24 V secondary), lead approx. 3 m with mains plug CEE 7/XVI, BS 1363, NEMA 1-15P
• Series accessories: TANEO wall bracket, magnifier 3.5 dpt (ø 132 mm, plastic lens), magnifier 4 dpt (100 x 50 mm, glass lens)
